Model No. | PH-ES524XTG_DMW01 |
UPC Code | 886523303688 |
Case Dimensions | 454 x 228 x 588 mm | 17.87 x 8.98 x 23.15 in |
Form Factor | Mid-Tower |
Mainboard Support | E-ATX, ATX, Micro-ATX, Mini-ITX (Up to 280 mm wide) |
Materials | Steel chassis, Aluminium panels, Tempered glass window, ABS plastic |
Color | Brushed black aluminium |
Expansion Slots | 8 |
Vertical GPU Support | Yes (Riser cable & bracket sold separately) |
Internal 2.5" Positions | 5 + 1x 3.5" HDD |
Internal 3.5" Positions | 2 + 3x 2.5" SSD |
Front I/O | 2x USB 3.0, 1x USB-C 3.2 Gen2x2, 1x Microphone/Headphone combo, Power button, Reset button |
Total Fans | 7 |
Fan Mounting Locations | Top: 3, Rear: 1, Bottom: 3 |
Radiator Support | Top: Max 360mm |
CPU Cooler Height | 170 mm | 6.69 in |
GPU Length | 380 mm | 14.96 in |
GPU Width | 170 mm | 6.69 in |
Power Supply Length | 250 mm | 9.84 in |
Top 360 Radiator Dimensions | 415 x 130 x 32 mm | 16.34 x 5.12 x 1.25 in |
Net Weight | 14.2 kg | 31.3 lbs |
Gross Weight | 16.5 kg | 36.4 lbs |
Warranty | 5 Years limited |
Scope of Delivery | 1x Evolv X2 chassis, 1x Storage bracket Pre-installed, 1x SSD bracket Pre-installed |
Accessory Box | 30x Mainboard/SSD screws, 4x Power supply screws, 8x HDD screws, 4x Vertical-GPU bracket screws, 1x Mainboard stand-off |
Additional Accessories | 6x Zip ties, 1x Stand-off removal tool, 1x D-RGB mainboard adapter 500 mm, 1x Microfiber cloth |
